Tuesday, May 2, 2017

Office of Energy Efficiency & Renewable Energy Electric Vehicle Community Readiness Resources

EERE EV Community Readiness Resources

U.S. Department of Energy, EV Everywhere Electric Vehicles: Stakeholder Solution Center

States and Municipalities

States and municipalities are key players in increasing EV readiness.  The best way for states and municipalities to improve their EV readiness is to partner with their local Clean Cities coalition, which can connect them to specific regional resources and other relevant stakeholders.

Employers

Providing charging at the workplace can encourage employees to purchase EVs, be an attractive employee benefit, and maximize all-electric miles driven by EV owners. The EV Everywhere Workplace Charging Challenge is a DOE program to have more than 500 employers provide workplace charging to their employees by 2018.

Fleets

Like consumers, fleets can benefit from the low operating costs and other benefits associated with EVs.  Local Clean Cities coalitions can help fleets decide which technologies and models will be most appropriate to meet their needs.

  • Handbook for Fleet Managers: This handbook on the DOE’s Alternative Fuels Data Center provides fleet-specific information on the basics of EVs, including issues like maintenance and charging.

  • Plug-in Electric Light, Medium and Heavy-Duty Vehicle Search: This tool on DOE’s Alternative Fuels Data Center provides information on EVs that can be filtered by class/type and manufacturer.

  • AFLEET Tool: Argonne National Laboratory’s Alternative Fuel Life-Cycle Environmental and Economic Transportation Tool allows fleet managers to calculate the cost of ownership, petroleum use, greenhouse gas emissions, and air pollutant emissions of alternative fuel vehicles.

Electrical Contractors and Inspectors

The installation of residential, workplace and public charging is essential to establishing an EV market.

  • Electric Vehicle Infrastructure Training Program: This program provides training and certification at community colleges and electrical training centers across the U.S. for people installing electric vehicle supply equipment for residential and commercial markets.

  • EVSE Residential Charging Installation Video: A series of segments on the Clean Cities TV YouTube channel walk electricians through the basics of installing EVSE in homes, including an overview of the equipment, the relevant National Electrical Codes, inspection, and best practices.

Utilities

Through our partnership with the Edison Electric Institute, DOE is developing a suite of tools for utilities to support the use of EVs.

  • The Utility Guide to Plug-in Electric Vehicle Readiness: A guide from the Edison Electric Institute, this document covers structuring your company to support EVs, adding EVs to utility fleets, enhancing the customer experience, working with state and local governments, and managing the electrical grid with EVs.

  • Utilities Power Change – This case study showcases how New Jersey's Public Service Electric and Gas Company, and Southern Company’s unit Georgia Power are launching workplace charging programs for their commercial customers.

Additional Resources

U.S. Department of Energy Workplace Charging Challenge Progress Update 2016: A New Sustainable Commute

At A Glance: Electric-Drive Vehicles

Charging Plug-In Electric Vehicles in Public

Charging Plug-In Electric Vehicles at Home

Resources for Electrical Contractors and Inspectors

Developing Infrastructure to Charge Plug-In Electric Vehicles

Plug-In Electric Vehicle Deployment Policy Tools: Zoning, Codes, and Parking Ordinances

Signage for Plug-In Electric Vehicle Charging Stations

Plug-In Electric Vehicle Handbook for Consumers

Workplace Charging: Charging Up University Campuses

Electric Vehicle Charging for Multi-Unit Dwellings (Webpage with links to resources and case studies)

Massachusetts Plug-in Electric Vehicle and Charging Infrastructure Case Study

Rolling Down the Arizona EV Highway (Case study)

San Diego Prepares for Electric Vehicles in Multi-Unit Dwelling Communities (Text version and video)

Houston Energizes Deployment of Plug-In Electric Vehicles (Case study)

Seattle Rideshare Fleet Adds EVs, Enjoys Success (Case study)

Alternative Fuels Data Center Publications (Search by keyword for additional resources)

Monday, May 1, 2017

Toyota Experimenting With Natural Gas Fuel Cells

Toyota is experimenting with using natural gas rather than hydrogen in a fuel cell vehicle.
The prototype hybrid system actually uses both fuel cells and a micro gas turbine to generate power. The turbine provides oxygen to the fuel cell in the form of compressed air. The oxygen reacts with the hydrogen and carbon monoxide to create electricity. Waste heat from the system is used to create additional power, and Toyota says the turbine is powered by leftovers from the process that splits natural gas into hydrogen and carbon monoxide.

Toyota claims the system is capable of generating 250 kilowatts of power, with 53 percent efficiency using only the fuel cell. Factoring in the use of waste heat to create power increases the system's overall efficiency to 65 percent, Toyota says, making it more efficient than a regular fuel cell. The fuel cell features a novel solid-oxide design that doesn't require a platinum catalyst, according to Toyota, and it operates at lower temperatures than conventional fuel cells.

How to compare the energy content of alternative fuels and gasoline or diesel

Question of the Month: How can I compare the energy content of alternative fuels and gasoline or diesel? What implications does this have for overall fuel and vehicle comparisons?

Answer:
Alternative fuels have varying energy densities and are measured using a number of different units, which can make comparing them tricky. The gasoline gallon equivalent (GGE) unit allows drivers to make apples-to-apples comparisons of a given quantity of energy from alternative fuels and assess which fuel best suits their needs. Understanding the energy content of fuels can help inform comparisons of fuel prices and vehicle driving range.

What is a GGE? How about a DGE?
A GGE is a standardized unit used to compare the energy content of all fuels. This unit quantifies the amount of alternative fuel that has the equivalent energy content of one gallon of conventional gasoline. For medium- and heavy-duty vehicle fuel applications, diesel gallon equivalent (DGE) is often used.

How are GGE and DGE values determined?
Energy content is measured in British thermal units (Btus) per gallon of fuel, and is often referred to as the lower heating value of the fuel. To calculate GGE and DGE, the energy content of one gallon of gasoline or diesel is divided by the energy content of the comparison fuel. For example, conventional gasoline has an energy content of 116,090 Btus per gallon, while propane has an energy content of 84,250 Btus per gallon. As such, 1.38 gallons of propane has the same amount of energy as one gallon of conventional gasoline.

The table below displays the energy content, GGE, and DGE values of conventional and alternative fuels.

Fuel
Energy Content*Quantity of Fuel in 1 GGEQuantity of Fuel in 1 DGE
Gasoline 116,090 Btu/gallon 1.00 gallon 1.11 gallon
Low Sulfur Diesel 128,488 Btu/gallon 0.90 gallon 1.00 gallon
Biodiesel (B20) 126,700 Btu/gallon 0.92 gallon 1.01 gallon
Biodiesel (B100) 119,550 Btu/gallon 0.97 gallon 1.07 gallon
Compressed Natural Gas (CNG) 923 Btu/cubic foot (ft3)
or
20,160 Btu/lb
125.77 ft3
or
5.76 lb
139.21 ft3
or
6.37 lb
Liquefied Natural Gas 21,240 Btu/lb 5.47 lb 6.05 lb
Ethanol (E100) 76,330 Btu/gallon 1.52 gallon 1.68 gallon
Ethanol (E85)** 88,258 Btu/gallon 1.32 gallon 1.46 gallon
Electricity*** 3,414 Btu/kilowatt hour (kWh) 34.00 kWh 37.64 kWh
Propane 84,250 Btu/gallon 1.38 gallon 1.53 gallon
Hydrogen 288.88 Btu/ft3
or
51,585 Btu/lb
401.86 ft3
or
2.25 lb
444.78 ft3
or
2.49 lb
*Lower heating value. Source for CNG and hydrogen (Btu/ft3): Transportation Energy Data Book, Edition 35. Source for remaining values: Alternative Fuels Data Center (AFDC) Fuel Properties.
** E85 that is sold in the United States today actually contains, on average, approximately 70% ethanol. Therefore, E85 energy content calculated as [(.70) x (E100 energy content)] + [(.30) x (gasoline energy content)]
*** Electric vehicles are more efficient (on a Btu basis) than combustion engines, which should be taken into account when calculating and comparing miles per GGE (see below).


The values in the table above can help standardize fuel amounts for comparisons. For example, if you have 10,000 ft3 of CNG, you can determine the equivalent number of GGEs by dividing by 125.77 ft3 to get 79.5 GGE. Similarly, to determine the number of DGEs, you would divide by 139.21 ft3 to get 71.83 DGE.

How are GGE and DGE used to compare fuel prices?
Fuel prices can be represented in dollars per GGE or DGE for consistency in pricing between fuels. For that reason, the Clean Cities Alternative Fuel Price Report shows prices on an energy-equivalent basis (Table 3 in recent reports). If values for price per GGE or DGE are not available, you can do the calculation on your own. For instance, if one gallon of E85 is $2.04, you would multiply by 1.32 (see table above) to find that this price equates to $2.69 per GGE after adjusting for energy content.

What are the factors that impact how far I can drive between fill ups?
The energy content of fuels is one factor that affects driving range. Filling up with a less energy-dense fuel often means that you will not be able to drive as far. However, tank size and vehicle efficiency also play a significant role.

Some alternative fuel vehicles (AFVs) have similar tank sizes to conventional vehicles, while others have larger fuel tanks to compensate for the difference in energy content. For example, vehicles that run on propane and biodiesel typically have similarly sized fuel tanks as their conventional fuel counterparts. As you can see in the table above, both of these fuels have lower energy densities than their conventional fuel counterparts, which subsequently can result in lower fuel economy and shorter range per tank. In the case of propane, bi-fuel vehicles are available that can operate on both conventional fuel and propane for extended driving range. In addition, propane and biodiesel offer many other benefits that can offset this difference.

CNG and hydrogen vehicles, on the other hand, often have larger tanks to offset the lower energy densities associated with these fuels. Fleets and drivers purchasing a CNG vehicle may have the option to install an additional CNG storage tank onboard the vehicle. Alternatively, bi-fuel CNG vehicles are also available to extend the range. As for hydrogen, these vehicles tend to have larger fuel tanks overall.

Tank size is not the only other factor that affects range; vehicle efficiency also plays a role. For instance, all-electric vehicles (EVs) are significantly more efficient than conventional gasoline vehicles. According to FuelEconomy.gov, EVs use anywhere from 59% to 62% of the electricity from the grid to power the vehicle, while conventional gasoline vehicles can only convert 17% to 21% of the energy from gasoline to power the vehicle. This is one reason why EVs have such significant fuel economy advantages over conventional vehicles, even when you are comparing the fuels on an energy-equivalent basis.


Clean Cities Technical Response Service Team
technicalresponse@icfi.com
800-254-6735

Thursday, April 27, 2017

California needs to develop renewable natural gas supplies

George Minter, vice president of external affairs and environmental strategy for SoCalGas wrote an op-ed piece for the Sacramento Bee about natural gas supplies in California.

"It’s wrong to say that we need to stop building gas infrastructure to focus on renewable energy. We need to invest more into developing the renewable gas supply and infrastructure to deliver this renewable energy to customers."
natural gas has helped the state drive down GHG emissions – not just by displacing dirtier fuels, but by filling in the gaps when the wind doesn’t blow and the sun doesn’t shine.

Integrating renewable electricity sources onto our grid relies on gas plants. Imagine if those plants were powered by renewable gas – we’d be getting twice the emissions reductions.

Saturday, April 15, 2017

Porsche 910 Converted to Electric

A Porsche 910 from the 1971 film Le Mans, starring Steve McQueen, has been converted to electric by a partnership between EVEX Fahrzeugbau and Kreisel.



It has double the power of the original Porsche 910, but is street legal (which the original one was not). More of these 910s will be converted, but Porsche manufactured only 35 of them, so the supply will be very limited.

The 1971 movie is available on DVD from Netflix or streaming from Amazon.

Monday, April 10, 2017

Los Angeles County MTA To Replace 1000 Diesel Buses

In May, the board of the Los Angeles County Metropolitan Transportation Authority will vote on a decision to replace 1,000 aging diesel buses with a combination of new compressed-natural gas models fueled by renewable natural gas and electric buses. 800 new buses will be fueled by renewable natural gas. The other 200 will be electric as a test program for future electrification.
The fact is, a predominant percentage of the geologic natural gas fueling transportation fleets in California has been replaced by renewable natural gas — produced from the decomposition of organic materials that is captured (avoiding greenhouse gas emissions and short-lived climate pollution) and conditioned to meet transportation fuel specifications.

Unlike geologic natural gas, renewable natural gas is not produced from hydraulic fracturing (fracking). Renewable natural gas is produced entirely from the methane emitted as organic materials decompose in renewable waste streams. It can then be injected into the existing common carrier pipelines and deployed through natural gas fueling stations, displacing CNG or LNG in medium- and heavy-duty vehicles like Metro's buses.

Monday, April 3, 2017

"How Volkswagen Is Shaping America's Energy Future"

T. Boone Pickens' suggestion for how to invest the fines paid by Volkswagen.
Volkswagen, the storied German automaker, pleaded guilty last week to three felony counts as part of a $4.3 billion settlement reached with the Justice Department in January over the automaker’s massive diesel emissions scandal.

There’s a great deal of irony in this, and a great opportunity for America’s energy security. Here’s why.

Back when President Obama rolled into the White House for the first time, I was in the midst of an aggressive campaign to address the stranglehold placed on our national security and our economy by addiction to OPEC oil.

The crux of that plan was to expand renewables (wind and solar) in power generation, and replace dirtier-burning and more expensive OPEC oil with our abundant supplies of cleaner-burning domestic natural gas in the transportation sector. The overarching goal was to break the stranglehold OPEC had on our economic and national security.

Washington lawmakers refused to foot the bill for America to go down that path. Now, in an ironic twist of fate, with the VW transgression, we have the Germans poised to finance it for us. And we’re fools if we don’t take advantage of this opportunity.
In 2015, the German automaker, Volkswagen, was found to have installed software on its diesel-powered vehicles that provided false emissions data — data that understated the emissions their vehicles were actually producing.

I’ve always been skeptical that diesel can ever burn as clean as alternatives such as electric cars or heavy-duty trucks fueled by natural gas. The lifecycle costs to produce diesel — from production to refining and out of the tailpipe — are just too great. Going to such lengths to falsify emission data just reinforces my skepticism, and my anger.

Since getting caught, the company has agreed to pay fines of $16 billion to settle claims for cheating. These fines will be paid to the U.S. government and shared among the states. In addition, owners of VW vehicles and the dealers who sold them will share in the proceeds.

We’re not talking chump change here. Texas alone, where I live, is set to get $191 million.

This flap once again underscores the need to get diesel vehicles off the road when and where we can, both for air quality purposes and to reduce our dependence on OPEC oil. One of the most toxic emissions produced by diesel engines is Nitrogen Oxide (NOx). It is generated by all internal combustion engines, but a new natural gas engine developed by Cummins-Westport produced 90 percent less NOx emissions than new diesel-powered trucks. That engine is available today.

State regulators ultimately tasked with spending the VW settlement should have some guidance from those with history, experience and knowledge — including industry, independent experts and environmental authorities.

First, a majority of the funds should be used for vehicles which already perform below current federal NOx limits, such as the Cummins Wesport engine mentioned above.

Second, all vehicles performing below federal NOx limits should be treated equally. States should look to decrease the number of diesel-powered vehicles on the road — especially heavy-duty trucks — and replace them with trucks powered by natural gas.

Why not go right to batteries? Because batteries will not move an 18-wheeler, and they cost at least five times more than comparable diesel-powered trucks. So, while electric cars are all the rage, batteries are not a substitute fuel source for over-the-road trucks.

Finally, while there will be justifiable efforts to use these funds on state fleets, it is even more important to find ways to allow private-sector fleets access to these funds. In fact, that’s where the bulk of the money should go.

Keeping in mind this settlement money is coming from a corporation and not the taxpayers, there will be no shortage of ideas from state regulators on how to spend these funds. States should show leadership by not using it solely to upgrade state fleet vehicles.

The reason is simple. If states use this money to replace aging fleets, this will be a “one-and-done” deal. On the other hand, if the money is used to provide incentives for the public and private sectors to purchase new, natural gas-powered vehicles, the positive effects on reducing NOx emissions will be magnified many times over the years.
